10 kS/s, 12-bit, 8チャンネルマルチファンクション USBモジュール
| | | USB-4702-AE |
| Analog Input | Channels | 8 SE/4 Diff |
| Sampling Rates | 10 kS/s |
| Resolution | 12 bits |
| Bipolar Inputs (V) | SE: ±10; Diff: ±1, ±1.25, ± 2, ± 2.5, ±4, ±5, ±10, ±20 |
| Analog Output | Resolution | 12 bits |
| General | Power Consumption | Typical: 5V @ 100 mA; Max.: 5 V @ 500 mA |
| I/O Connectors | 1 x DB37 |
| Dimensions (L x W x H) | 70 x 70 mm (2.76" x 2.76") |
| Bus | USB 2.0 |
| Timer/Counter | Resolution | 32 bits |
| Time Base | 5 MHz |
| Channels | 1 |
| TTL DI/O | Input Channels | 8 |
| Output Channels | 8 |
|
パーツナンバー
|
詳細
|
Get Quote
|
|
|
|
|
| USB-4702-AE | 10 kS/s, 12-bit, 8-ch Multifunction USB Module | Get Quote |
USB-4702は、実験等に使用することのできる8チャンネル、12ビット、10 kS/秒のマルチ機能USB DAQモジュールです。
低コストで、基本的な機能を必要とする顧客を対象としており、学生や研修用にお勧めの製品です。
